Oil Pump - Cast Iron
| Ref | Part # | Description | Price | Qty. required | |
| 1 | 86863 | CAST IRON OIL PUMP, assembly, (distributor models) | 1 | currently unavailable | |
| 2 | 41373 | DISTRIBUTOR SLEEVE, 1.143'' long; Cad Plated | $13.50 | 1 | |
| 3 | 41372 | BUSHING, distributor drive shaft | $15.00 | 1 | |
| 4 | 101030 | GEAR, distributor, 11 tooth, left hand gear | $80.00 | 1 | |
| 5 | 101031 | PIN, 1/8'' X 3/4'' roll pin, (replaces rivet) | $1.50 | 1 | |
| 6 | 41369 | RETURN GEAR PUMP DRIVE SHAFT, | $32.50 | 1 | |
| 7 | JG-2361 | SCAVENGE GEARS, return pump drive and driven | $75.00 | 1 | |
| 8 | 36B37 | KEY, Special | $3.50 | 1 | |
| 9 | 41496 | IDLER GEAR SHAFT, return pump | $19.50 | 1 | |
| 10 | 41356 | PLUNGER FEED PUMP, .503 O.D | $175.00 | 1 | |
| 11 | JG-2411 |
GASKETS, Cast Iron Oil Pump lower body cover
- Kit
( Includes reference numbers:
(1) of GASKET, Cast Iron Oil Pump lower body .003'' thick, Order JG-2411 - 41355
(1) of GASKET, Cast Iron Oil Pump lower body .005'' thick, Order Kit JG-2411 - 43017
) |
$4.00 | 1 | |
| 12 | 75202 | OIL PUMP LOWER BODY COVER; | 1 | currently unavailable | |
| 13 | JG-2362 | FASTENERS, Cast Iron Oil Pump body | $30.00 | 1 | |
| 14 | 751523 | SCREW, #12-24 X 2.250''(Fillister Head) | $3.75 | 3 | |
| 15 | 751521 | SCREW, #12-24 X 2"(Fillister Head) | $3.00 | 1 | |
| 16 | 751517 | SCREW, #12-24 X 1.500''(Fillister Head) | $1.00 | 1 | |
| 17 | 751513 | SCREW, #12-24 X 1"(Fillister Head) | $1.75 | 1 | |
| 18 | 751509 | SCREW, #12-24 X .625''(Fillister Head) | $1.75 | 4 | |
| 19 | 751507 | SCREW, #12-24 X .500''(Fillister Head) | $1.25 | 1 | |
| 20 | 922005 | WASHER, #12 Split Lock; Cad Plated | $0.75 | 11 | |
| 21 | 45009 | SET SCREW, 1/4''-20 X 1.250''(Blunt nose), sleeve to housing | $6.50 | 1 | |
| 22 | 45010 | SET SCREW, 1/4''20 X 0.750''(Pointed Nose), bushing to housing | $8.50 | 1 | |
| 23 | 42542 | PLUNGER GUIDE SCREW, 5/16''-24 X .378'' long | $13.00 | 1 | |
| 24 | 41374 | GASKET, cast iron oil pump to cam case cover | $3.00 | 1 | |
| 25 | 41367 | PLUNGER FEED CAP, with rod; Cad Plated | $25.00 | 1 | |
| 26 | 37620 | WASHER, 3/4'', .050'' thick, plunger feed cap; Lead | $3.00 | 1 | |
| 27 | 36B269 | PLUG, 1/4'' NPT(Square Head), Magnet; Cad Plated | $7.25 | 1 | |
| 28 | 661001 | PLUG, 1/8''NPT(Slotted) | $4.00 | 4 | |
| 29 | 24B16 | ELBOW, 7/16''-24 X 1/2''-24 (5/16'' hole); Nickel Plated | $19.50 | 1 | |
| 30 | 24B17 | NUT, 7/16''-24(Hex); Cad Plated | $2.50 | 1 | |
| 31 | A21120 | WASHER, 7/16'', .031'' thick, Lead | $1.50 | 2 | |
| 32 | 37569 | WASHERS, 7/16'', includes lead and copper washer | $5.50 | 2 | |
| 33 | 41819 | NIPPLE, 7/16''-24 x 1/2''-24, 1.03'' long, (5/16" hole), body return tube; Cad Plated | $12.00 | 1 | |
| 34 | 41818 | NIPPLE, 1/2''-24 X 9/16''-24 1.04'' long; Cad Plated | $12.00 | 1 | |
| 35 | 937003 | WASHERS, 1/2'' includes lead and copper washers | $4.75 | 1 | |
| 36 | 37523 | WASHER, 1/2'' I.D, .055'' thick, Flat, lead | $2.00 | 1 | |
| 37 | 41366 | DISTRIBUTOR HOLE CAP, Cad Plated | $28.00 | 1 |
